TTP933-LED驱动芯片
首页 > 产品中心 > IC系列 > LCD与LED类 > TTP933-LED驱动芯片

产品描述PDF下载

General Description

TTP933is a high efficiency , constant current , continuous mode inductive step-down converter,designed for driving constant current to high power (single or multiple) LED with only 4 external components. TTP933 operates from input supply between 5V and 33V and provides an externally adjustable output current of up to 1.5A.

The TTP933 is specifically designed with PFM control to enhance the efficiency up to 97% .

The Output current can be modify by an external resister , and can adjusted , by applying an external control signal to the DIM pin , The DIM pin will accept a PWM waveform.

Additionally , to ensure the system reliability , TTP933 is built-in with over temperature protection , and LED open-circuit short-circuit protection to protect system from being damaged .

Features

1.5A output current

Wide input voltage range: 5V to 33V

High efficiency (up to 97%)

Internal NDMOS power switch

Single pin on/off and brightness control using PWM Hysteretic PFM improves efficiency at light loads With Thermal/Soft start /LED open-short detect protection

Only 4 External Components Up to 1Mhz switching frequency Typical 3% output current accuracy

Applications

High power LED lighting

Automotive LED lighting

Low voltage industrial lighting

LED back-up lighting

Constant Current Source
